Types of Computer Network Explained in Easy Language

This tutorial explains the different types of computer network such as LAN, MAN, WAN, PAN, CAN, GAN, Internet, internet, Intranet, Extranet, VPN, Client/Server, Workgroup and HomeGroup in detail. Learn the different types of computer network including their definitions and characteristics in easy language.

What is a computer network?

A computer network is a group of two or more computers connected with each other for sharing resources and information. A simple computer network can be built only from two computers while a complex computer network can be built from several thousand computers.

Types of computer network

A computer network can be categorized based on geographical location and characteristic. Based on geographical location, computer networks are outlined below.

LAN (Local Area Network)

A LAN is a computer network which spans over a small geographical area such as home, building, office, etc. In LAN, computers are placed relatively close. Since computers are located within small distance, they do not need special devices and cables to connect with each other.

computer network type lan

MAN (Metropolitan area networks)

A MAN is a computer network which connects two or more LAN networks within same city. When due to distance connecting two LANs is not possible, MAN network is used. It is larger than LAN but smaller than WAN. It deploys special devices and cables to connect the LANs.

computer network type man

WAN (Wide Area Network)

WAN is a computer network which spans over a large geographical area such as state, region, country etc. WANs are typically used to connect two or more LANs or MANs which are located relatively very far from each other. To provide connectivity, this network uses special devices, cables and technologies.

computer network type wan

Above categorization (LAN, MAN and WAN) of computer network is purely based on geographical location. It has nothing to do with the number of computers in each network. For example, if one computer is located in Delhi and other computer is located in Mumbai, connecting these two computers is the example of WAN networking. Just like this, if a company starts a new branch office with 500 computers and all these computers are installed within a building, this network will be considered as a LAN network.

There are three more types of computer network based on geographical location but they are rarely used to define the network. In real life you may skip these but if you preparing for job interview or for any networking exam, you should learn these also.

PAN (Pearson Area Network)

Same as LAN network, but it is limited to a specific person or location such as home network. This network is usually setup for sharing resources such as internet and printer within personal computers.

computer network type pan

CAN (Campus Area Network)

Same as MAN network, but it is limited to a university or an academy. This network is usually setup for educational activities such as classroom updates, practices labs, emails, exams, notifications, polls, etc.

computer network type

GAN (Global Area Networks)

Same as WAN network, but it covers unlimited geographical area. For example a company has an office in Delhi and another one Washington D.C., connecting these two offices will be considered as a GAN network. In other words, GAN is a computer network which connects two or more WANs. This network is increasingly gaining popularity as many companies are expending their working area beyond their native countries.

computer network type gan

So far, we have discussed the types of computer based on geographical location. In following section we will understand the types of computer network based on characteristic.

Internet

This is the largest computer network ever created by mankind. It interconnects thousands of millions of computing devices including PCs, Laptops, Workstations, Server, Smartphones, tablets, TVs, Webcams, Environmental devices, Automobiles, Security cameras and many mores. According to a report published in January 2018, there were 2150 million end systems connected with the Internet. To connect these devices, a lot of technologies and infrastructure are used. Internet is open for everyone. Anyone can connect with it. Since anyone can connect with it, it is also considered as the most insecure network.

computer network type internet

internet

The internet sounds similar to Internet but it is different. The word Internet starts with capital I, while the word internet begins with small i. Any group of network which is connected with external network through a gateway such as BGP is considered as internet. Usually this type of network is setup to provide the connectivity between two companies.

Intranet

Intranet is a computer network which is controlled and administered by a single entity such as company or organization. In Intranet, external users are not allowed to connect. Usually in this network, proper authorization is required to access any resources. Further each access is monitored and logged to ensure that only authorized users get access.

Extranet

An Extranet is an extended Intranet where external users are allowed to access a small portion of network. Normally this access is filtered and secured by several security implementations on both hardware and software levels.

VPN (Virtual Private Network)

VPN is the cost effective solution to utilize the goodies of Internet. Companies which can’t afford their own infrastructure for connectivity can use VPN. VPN provides a secure connection over the Internet. For example a company has two offices; one in Delhi and other in Mumbai. Now suppose, company can’t afford a dedicate line to connect these two offices. In this case company can use VPN to connect both offices. VPN creates a secure line over the Internet and uses it for data transmission.

computer network type vpn

Client/Server Network

In this network, a dedicate computer known as server provides sharing resources. All other computers know as clients are used to access the shared resources. This type of network is commonly used in company environment. It provides great security features but requires special hardware and software to setup.

computer network type server client

Workgroup Network

In this network, all computers are equal. Any computer can provide and access shared resources. This type of network is usually used in small office or home network. It is easy to setup and does not require any special hardware and software. The downside of this network is that it provides very less security.

computer network type workgroup

That’s all for this tutorial. For any suggestion, feedback or comment about this tutorial, please mail me. I really love to listen from you. If you like this tutorial, please share it with friends.
